Rated Capacities

60，100，150，200，250，300，350，500（kg）

Rated Output

2.0 mV/V±0.25%

Non-linearity

0.02% R.O.

Hysteresis

0.02% R.O.

Repeatability

0.02% R.O.

Creep(30min)

0.02% R.O.

Temperature Effect On Output

0.002%R.O./℃

Temperature Effect On Zero

0.003%R.O./℃

Zero Balance

±0.0200 mV/V

Input Impedance

410±15 Ω

Output Impedance

350±5 Ω

Insulation Impedance

≥5000MΩ/(50VDC)

Safe Overload

150% R.O.

Ultimate Overload

200% R.O.

Operating Temperature Range

-20~60 ℃

Recommended Excitation

5~12 VDC

Maximum Excitation

15 VDC

Construction

Aluminum Alloy

Protection Class

IP66 / IP67

Cable

φ6×6 m

Platform Size

350×450 mm

Mode of Connection

Red（EXC+）,Black（EXC-）,Green（SIG+）,White（SIG-）
